Automatic fly ash brick plant 4500
| sr No | Particulars | Fly Ash Brick Plant ( FBP 4500 ) Model |
|---|---|---|
| 1 | Bricks Press Type | Automatic Hydraulic Bricks Press with hi-tech Prefill Technology. |
| 2 | Bricks Press Body | Heavy Duty Window type Body Fabricated M S Plate by CNC Plasma Cutting Machine. |
| 3 | Brick Production Ratio | 4500 Bricks/Hour Max. |
| 4 | Brick per stroke | 21 Brick |
| 5 | Bricks Size(mm) | 230 (L) X 110 (W) X 75 (H) – Size Option Available |
| 6 | Bricks Press Tonnage | 210 MT |
| 7 | Palletizer system | Portable Type |
| 8 | Pallet Feeding System | Automatic |
| 9 | Pallet Use in Plant | 90 Nos |
| 10 | pallet Size | 990mm x 840mm x 25 mm – wooden pallet |
| 11 | Mixer Type | Pan Mixer – 2 Nos |
| 12 | Mixer Capacity | 750 kg Max. per Batch. |
| 13 | Pan Mixer Motor | 10 HP / 5.71 KW |
| 14 | Pan Mixer Gear Box | Planetary Gear Box |
| 15 | Mixer Speed | 26 – 28 RPM |
| 16 | Mixing Arms | 2 Nos. per Mixer |
| 17 | Crushing Rollers | 2 Nos. per Mixer |
| 18 | Pan Mixer Feeding | Manual / Automatic Feeding Available as Optional10 |
| 19 | Pan Mixer Gate | Manual / Hydraulic Gate Available as Optional |
| 20 | Pan Mixer Water Automation | Available as Optional ( Additional cost ) |
| 21 | Hydraulic Motor | 30 HP / 17.41 KW |
| 22 | Hydraulic Valves | YUKEN Make / 240 VAC |
| 23 | High Pressure Pump | YUKEN Make VAN Pump |
| 24 | High Flow Pump | YUKEN Make VAN Pump |
| 25 | Oil Cooling system | Water Cooling |
| 26 | Control Panel | Delta make : P L C Based Control Panel |
| 27 | Men Power | 2 – Operator , 15 – labor |
| 28 | Total Power | 58 HP / 43.5 KW |
| 29 | Machine warranty | 1 year |
| Note: All of the Specifications, Dimensions & Designs are Subjected to change without Prior Notice. Please confirm the details at the time of Order Finalization. Check Commercial Terms & Condition. | ||
Intelligent circle design offers the best quality facilities and apparatus for making lightweight cellular (c l c) concrete blocks. The cellular lightweight concrete block plant (c l c) is mainly composed of important units such as belt mixer, foam generator, air blower, advanced calibration structure, and molds. The grouping of programmed material and the care of the structure, as well as the wire cutting machine, is also accessible as discretionary.
The cell lightweight concrete block plant (c l c) can be accessed in after three models; 1. Light cellular concrete block plant (clc) – limit: 15 cumtr per shift 2. Light cellular concrete block plant (clc) – limit: 30 cumtr per shift 3. Light cellular concrete block plant (clc) – Limit: With this hardware, it is possible to deliver lightweight blocks of 50 cumtr per shift cell with a thickness from 600 kgcubmtre to 1400 kgcubmtr.
The grouping of programmed material, the care of the structure, and the wire cut structure are also accessible as discretionary. Get in touch for more niceties.
The organization is basically busy with assembling, marketing, and supplying brick/block/paver machines everywhere. The Plant, delivered by us, is superior in grades, execution, and useful life. The plant can benefit from us at ruthless costs and the highest rank in production capacities and degree of automation.
